Embedded Access Control Board
1.Product Description:
This is a control panel that uses a contactless induction card for access control. It is easy to use and has reliable performance.
2.Technical Parameters：
| Operating voltage | DC 12V±10% |
| Working current | <100mA |
| Dimensions | 90mm*36mm*16mm |
| Temperature | -20℃-60℃ |
| User capacity | 15000 Cards |
| Card reader type | EM Card (ID Card）/Anti-copy ID Card |
| Reading distance | 1-10cm |
3.Steps to set up the management card and restore factory settings：
Step 1: Disconnect the power supply, jump the jumper cap on the S1 pin to pins 2 and 3, and then power on again. After three long beeps, the green light flashes quickly (the menu password is now restored to 123456)
Step 2: Swipe two blank cards in succession (the first is "add card", the second is "delete card"), then the red light flashes slowly, and there are continuous short beeps, indicating that the management card is set successfully
Step 3: Disconnect the power supply again, jump the jumper cap on the S1 pin back to pins 1 and 2, and then power on again
